Maximum street legal width of 8.5 FT. This trailer has massive ramps which measure 10 FT in length including the dovetail. Huge lockable toolbox in the neck and a stainless steel underbody mounted tool box as well. 14-ply tires for trouble-free service with spare included. 30” Rear LED light bar for loading. A 3/4 Ton Truck or better with a bed mounted gooseneck hitch is required to pull this trailer.
Size of ball required: GOOSENECK 2 5/16”
Frame 14 Inch Beam and 12 Inch Neck
Lighting Connector: 7-way Round
2 Braking Axles
(2) 12K Single Speed Jacks
Stake pockets and strap rail with (10) frame mounted 4” straps
Tires 14 Ply with maximum allowable tire pressure: 80 PSI
Trailer Weight: 7,700 LBS
Maximum Cargo Capacity: 16,000 LBS
Ramps 40 Inch Triple Spring Assisted Goliath Big Ramps
Dovetail + Ramp Length is 10 FT
Deck Height is 33”
